32″ Surgical Displays


Back To Category >

The 32″ DBI32S surgical LCD system provides a superior solution to fit all stringent surgical imaging requirements. With full HD resolution, ultra high brightness and contrast, it is the monitor of choice for the OR and ER. The DBI32S delivers bold, vibrant, images even when viewed from a distance. It supports a variety of video inputs for existing and new camera technologies, eliminates costly signal conversion, image degradation and image lag. This surgical display features exceptionally fast response time necessary when viewing live video or motion.

SKU: DBI32S

Description

LCD size/type 32″ Surgical LCD
Resolution 1920 x 1080
Recommended Modalities Surgical, IPX1 Rated
Aspect ratio True 16:9
Brightness 500 cd/m2
View Angle 178º (left/Right)/170º (Up/Down)
Contrast Ratio 1300:1
Luminance Stabilization Embedded Auto Luminance Stabilizer (ALS)
Color/ Color Gamut 16.8 million
GPIP Port Swap, PIP/PBP/PBP2 Select, Record Indicator
Input Connectivity
DVI x 1, DVI x 2 (Optical Fiber Optional), D-Sub 15-pin mini x 1 (RGB Analog), BNC x 1 (3G-SDI), BNC x 1(CVBS), BNC x 2 (SVHS Y/C), BNC x 5 (Component Y/G, Pb/B, Pb/R, H/CS)
Dimension (w*h*d) 31.3″ x 19.1″ x 3.9″ Without Base
Weight w/o base 34.8 lbs.
Power Consumption Less than 100W
Power Supply Internal
Regulatory Approvals EN60601-1-2 : 2001, IEC 60601-1, Rule 12, MDD 93/42/EEC, IEC 60950-1:2001, FCC Part 15 Subpart B Class B, UL 60601-1, CAN/CSA-C22.2 No.601.1-M90, CCC (FS-L1901D, FS-L2401D, FS-P2601D, FS-P2603D)

Service & Warranty

Warranty 2 Years on LCD, backlight, and electronics

Product Sheet


Download Printable PDF : 154 Kb
